PART NUMBER:76-9440/439088B
ITW switch Black mushroom Pushbutton with IP67 rate.
The push button suited to harsh environments and applications
where high impacts are possible.
ITW switch are able to survive an impact of a 5kg mass dropped
from 40cm and are panel sealed to IP67.
The bezels and actuators designed from non-sparking zinc alloy.
Single pole panel mounting switches.
Large circular style suitable for applications where a
large actuation area is required and is available in momentary and ’pull-to-reset’ latching versions
Silver contacts
Panel sealed to IP67
Non-sparking alloy
Additional information
| Switch Type | Pushbutton |
|---|---|
| Switch Operation | Momentary |
| Actuator Type | Large Round (Mushroom) Button |
| Actuator / Cap Color | Black |
| Case Color | Black |
| Contact Configuration | SPDT-NC-DB |
| Operating Force (Nom) | 7N / 25.2ozf |
| Contact Material | Fine Silver |
| Contact Voltage AC Nom | 250V |
| Contact Voltage DC Max | Not Applicable |
| Contact Current AC Max | 10A |
| Contact Current DC Max | Not Applicable |
| Illuminated | Non Illuminated |
| Illumination Color | Not Applicable |
| Illumination Voltage | Not Applicable |
| Switch Mounting | Threaded Bushing |
| Panel Cutout (H x W) | 22 x 20 |
| IP Rating | IP67 |
| Legend | Not Applicable |
| Operating Temperature Range | -40°C to +125°C |
| Standards Met | Not Applicable |
| Mechanical Life | 2000000 |
| Electrical Life | 100000 |
| Product Series | 76-94 |
